SOFTWARE
Infinition, Canada
TestCenter 6
The well-known Software for analyzing Doppler signals. A quick and effective way to get results is through application optimization!
Description
A Windows-based software called Test Center offers an interface for calculations and analysis for ballistic instrumentation of various kinds of projectiles. With the help of this multitasking programme, the operator can access and begin evaluating the data even before the capture is complete.
Features:
- Highly compatible with Windows XP, 7, 8 from Microsoft;
- Requires Conventional Pentium based PC
- Multiple test configuration definitions for the acquisition and analysis parameters that are user defined;
- All channels’ raw data is recorded and preserved on disk;
- Multiple contexts for analysis that allow multiple studies to be carried out at the same time (for instance, dual muzzle velocity measurement by using 2 radars);
- Analysis of velocity, analysis of modulation (spin), analysis of drag and trajectory, in-bore measurement, measurement of rate of fire and so on;
- Multitasking (concurrent) data collection, processing, and result presentation for optimal responsiveness;
- Microsoft Excel based advanced report generation;
- Tracking multiple objects;
- Trajectory prediction using the PM and MPM ballistic models
Extra Data for Software
(if required)
DATA PROCESSING
The Test Center application is a strong instrument for measuring the velocity of standard projectiles, base bleed, tracers, sub-calibers, rockets, etc. when used in conjunction with Infinition CW Doppler radar systems.
REPORT GENERATION
Highly customizable & advanced report generation based on Microsoft Excel.
NETWORK INTEGRATION & REMOTE ACCESS
TestCenter includes a library that can be linked with another piece of software to provide remote access to the data available in TestCenter as well as control of the acquisition over a TCP/IP network, a serial connection, or LabVIEW in order to provide the greatest amount of flexibility and interoperability. This feature enables you to centralize acquisition control and data access by integrating TestCenter with various measurement systems in your analysis environment.
LICENSING
Various licensing of TestCenter exists to fit the needs of every customer. To fit the needs of every customer, there are various licensing of TestCenter.
